Model Number: FL-5.2C
Features:
1)Split design,ultra-low noise
2)Ceiling mounted,save space
3)Panasonic compressor, long service life
4)Programmable PLC controller
5)Brand electronic spare parts,stable quality
6)RS485(optional)
| Model | FL-5.2C |
| Cooling capacity | 5.2KW |
| Suitable area | 10-15㎡ |
| Air volume | 980m³/h |
| Temperature/humidity control range | 16-28℃±1℃；RH45-75%±5% |
| Refrigerant gas | R22/R410A/R407C |
| Heating type | Electrical heater |
| Humidification type | Atomization/Wet film humidification |
| Water intake method | Automatic or manual |
| Humidity capacity | 3kg/h |
| Voltage of indoor machine | 220V/50HZ |
| Voltage of outdoor machine | |
| Relay | Schneider |
| AC contactor | |
| Control system | Programmable PLC with LCD touch screen |
| Power input | 4.3kw |
| Indoor machine dimension(L*W*H) | 1164*685*360mm |
| Outdoor machine dimension(L*W*H) | 950*350*840mm |
| Indoor machine N.W. | 70KG |
| Outdoor machine N.W. | 78KG |
